Teledyne LeCroy Launching Your Analyzer
30 SierraNet M408 User Manual
Figure 1.22: Static IP Setup Dialog
Static Configurations
Within static configurations, SierraNet M408 must be manually programmed with an IP
address, Subnet Mask and a default GATEWAY.
Once SierraNet M408 has been programmed with the static network configuration, it will
broadcast a UDP message on its own subnet stating that is on line and available for
connection.
Note: This broadcast is only on the subnet that includes the SierraNet M408 System.
When the application is started on the host machine, it will broadcast a UDP message on
its own subnet asking all SierraNet M408s available to identify themselves.
Note: This broadcast is only on the host machine's subnet.
If the host machine and the SierraNet M408 System reside on the same subnet, they will
see each other’s broadcasts and the application will automatically populate the Select
Device list.
2. To change to Static IP, click the Static IP radio button.
Enter the Static IP Address.
Enter the Subnet Mask.
Click Update.
The system displays a warning message.
Click Yes to get a success message.
Click OK. The message closes and the device resets.
3. To change back to DHCP, in the IP setup dialog, click the DHCP radio button, then
click Update.
