LeCroy Corporation InFusion Scenarios
206 SierraNet M408 Protocol Analyzer User Manual
Note:
You can specify additional Sequences and States. The application automatically checks for the
maximum number of terms (sequences/states). When you exceed the limit, an error is flagged,
prompting you to jump to the place that caused the error.
Creating InFusion Scenarios is easy, but it requires an understanding of the following
terms defined in Table 4.3.
VSAN‐FCVI(SEND_RQST) Refer to section “FCVI Patterns” on page 136.
VSAN‐
FCVI(WRITE_RQST) Refer to section “FCVI Patterns” on page 136.
VSAN‐FCVI(READ_RQST) Refer to section “FCVI Patterns” on page 136.
VSAN‐FCVI(SEND_RESP) Refer to section “FCVI Patterns” on page 136.
VSAN‐FCVI(WRITE_RESP) Refer to section “FCVI Patterns” on page 136.
VSAN‐FCVI(READ_RESP) Refer to section “FCVI Patterns” on page 136.
VSAN‐
FCVI(CONNECT_RQST) Refer to section “FCVI Patterns” on page 136.
VSAN‐
FCVI(DISCONNECT_RQST) Refer to section “FCVI Patterns” on page 136.
VSAN‐
FCVI(CONNECT_RESP1) Refer to section “FCVI Patterns” on page 136.
VSAN‐
FCVI(CONNECT_RESP2) Refer to section “FCVI Patterns” on page 136.
VSAN‐
FCVI(CONNECT_RESP3) Refer to section “FCVI Patterns” on page 136.
VSAN‐
FCVI(DISCONNECT_RESP) Refer to section “FCVI Patterns” on page 136.
FCAV
VSAN‐FCAV(Simple)
Refer to section “FCAV Patterns” on page 137.
VSAN‐FCAV(Extended) Refer to section “FCAV Patterns” on page 137.
FIP Refer to section “FIP Patterns” on page 106.
MPCP Refer to section “MPCP Pattern” on page 107.
Address Resolution
Protocol Refer to section “Address Resolution Protocol Pattern” on
page 108.
Link Layer Discovery
Protocol Refer to section “Link Layer Discovery Protocol Pattern” on
page 109.
Internet Protocol Refer to section “Internet Protocol Pattern” on page 110.
iSCSI Refer to section “iSCSI Pattern” on page 111.
VLAN Refer to section “ISL Patterns” on page 113.
ISL Refer to section “ISL Patterns” on page 113.
CN‐Tag Refer to section “CN Tag Patterns” on page 114.
VN‐Tag Refer to section “VN Tag Patterns” on page 114.
Trill Frame Refer to section “LLC” on page 115.
Protocol Errors Refer to section “Protocol Errors” on page 117.
Event Description
