Teledyne LeCroy Preferences
178 SierraNet M408 User Manual
4. Select the command, double‐click or right‐click, and select Match Fields. The
following dialog displays (see Figure 3.42 ).
5. Enter the values in the fields.
6. Click OK twice.
Figure 3.42: Find LUNs and LBAs 2
3.6 Preferences
The Analyzer ships with a default configuration for software settings, port alias, address
alias, display and sequencer settings. You can define your own settings for a particular
testing scenario. To set these preferences select Setup > Preferences or click the
icon on the main toolbar to display the Preferences dialog (see Figure 3.43 on page 179 ).
