Teledyne LeCroy Filtering
172 SierraNet M408 User Manual
Save Filter
After you have set up a Filter configuration, you can save it as a Filter file by clicking Save.
Load
You can use a previously saved filter by clicking Load in the Filter dialog.
Apply
You can apply the current filter by clicking Apply in the Filter dialog.
Filtering LUNs and LBAs
Perform the following steps to filter for LUNs and LBAs:
1. Click the Filter icon to display the Quick Filter dialog.
2. Click Advanced to display the Hide/Show dialog.
3. Select FCP_CMD in the left pane and drag it in to the right pane or click the right
arrow.
Figure 3.34: Filtering for LUNs and LBAs

4. Select the command, double‐click or right‐click, and select Match Fields. The
following filter dialog displays (see Figure 3.33 on page 171 ).
