MOD 30ML Functions
DISPLAY INTERFACE BLOCK
Display Interface Block Page 3
Use this page to set values for display flash periods, and set values for display flash and
beep characteristics,
Figure 2-11. Display Interface, Typical Block Connections
Action on low priority alarm
Flash display (See attribute 25 description.) Use to specify if an unacknowledged low
priority process alarm (from PAD Block) will cause the entire display to flash. The LED
always flashes on an unacknowledged alarm.
Beep (See attribute 26 description.) Use to specify if an unacknowledged low priority
process alarm (from PAD Block) will cause the beeper to beep.
Rate (See attribute 27 description.) Low Priority process alarm flash rate for LED, display
and beeper.
Low/High priority breakpoint (See attribute 18 description.)
All process alarms with priority >= this value (2 - 255) are considered LOW priority for
display purposes.
Action on high priority alarm
Flash display (See attribute 22 description.) Use to specify if an unacknowledged high
priority process alarm (from PAD Block) will cause the entire display to flash. The LED
always flashes on an unacknowledged alarm.
Beep (See attribute 23 description.) Use to specify if an unacknowledged high priority
process alarm (from PAD Block) will cause the beeper to beep.
Rate (See attribute 24 description.) High Priority process alarm flash rate for LED, display
and beeper.
