MOD 30ML Functions
CONFIGURATION EXAMPLES
3.3 CONFIGURATION EXAMPLES USING THE APPLICATION BUILDER
SOFTWARE
The configurations described in this section support the concepts of using the Display (DISP),
Display Interface (DIF), State Table (ST), Tune List (TL) and Process Alarm Display (PAD)
functions used specifically used by the MOD 30ML instrument. These configuration concepts
are presented using a single PID loop with alarms and then adding a totalizer and using a
cascade PID loop and adding a CJC compound as examples. Other compounds are shipped
with the Application Builder but are not described here.
3.3.1 GETTING STARTED WITH THTE APPLICATION BUILDER SOFTWARE
Based on the assumption that the Application Builder software is installed as described in the
IB-23H141 User’s Guide, a new strategy is initiated as follows:
1. Access the DOS Prompt for the drive and directory where the Application Builder resides.
The following prompt appears:
C:\APPBLD
If the drive and directory are other than C and APPBLD, the applicable prompt appears
instead of C:\APPBLD.
2. Type STRATEGY and press the ENTER key. The UNTITLED [ROOT] display appears in the
Select mode with the workspace empty.
3. From the tool bar select the Library icon. The System Library menu appears.
4. Select the MOD 30ML type of instrument (both MODCELL and MOD 30ML may be
available). The instrument library appears on the left side of the display.
5. Select an instrument from the left and place it in the work space. A block representing the
selected instrument appears. The block is identified with a default tag (i. e., 001).
6. Select and query the block to access the block identification window, then Select the Block
Tag field and type the name you wish to assign to the block.
7. Select the Enter button to close the window. The instrument block with your assigned tag
name appears in the workspace.
8. Double click on the instrument block. The block is removed from the work space and the
environment blocks appear; (IF, SE, DIF, and ST). This is the Instrument Level of your
strategy, Figure 3-34A.
3-26
