MOD 30ML Functions
DISPLAY INTERFACE BLOCK
Field
Mnemonic
Valid Values
CWR
Data Type
Attr
Port 3 Noise Counter
NOISECTR
– WR Count
28
Port 3 Buffer Full Counter
BFULLCTR
– WR Count
29
Port 3 Communications Error
Counter
CMERRCTR
– WR Count
30
Keyboard Error Counter
KBERRCTR
– WR Count
31
Flash Periods: Slow - Off Counts SFOFFCNT
CWR Long State
32
Flash Periods: Slow - On Counts SFONCNT
CWR Long State
33
Flash Periods: Fast - Off Counts FFOFFCNT
CWR Long State
34
Flash Periods: Fast - On Counts FFONCNT
CWR Long State
35
Flash Periods: Activity - Off
Counts
ACOFFCNT
CWR Long State
36
Flash Periods: Activity - On
Counts
ACONCNT .
CWR Long State
37
Entry Timeout
ENTRTIME NONE (65535),
CWR Count
38
Date Format
DATEFMT US (0), or EURO (1).
CWR Discrete
39
Shutdown Instrument on
Faceplate Comm Failure
SHUTFAIL NO (0), YES (1).
CWR Discrete
40
Remote Display Number Input
REMDISP
CWR Count
60
Block Type
DIF
This is the display interface block type.
00
Block Version (VERSION) ................................................................................................ – – R
The display interface block is at version 1.
01
Block Length (BLKLEN) .................................................................................................... – – R
Number of database bytes taken by the block. Always an even number.
02
State (STATE) .................................................................................................................... CWR
Block state is always RUN. See IB-23G600 (Logic Book 1) Section 2.4.1, State Changes
for additional information on block states.
RUN
0 Normal Operation. Block is always executed.
03
Bad Inputs Accepted (BADINP) ....................................................................................... CWR
See IB-23G600 (Logic Book 1) Section 2.3.2, Data Quality for additional information.
Rejected
0 Block checks data quality on its inputs and, if it is BAD, no action will be
taken on the input and display selection will revert to the TAG key.
Accepted
1 Block runs its algorithm without a check on input quality.
04
Diagnostic Group (SUPPGRP)......................................................................................... CWR
The diagnostic error reported by this block can be grouped for System Event block control of
its reporting. The selections are:
NONE
No group assigned.
1 to 7
Defines the diagnostic group number for the diagnostic suppression group
controlled by the System Event block.
