MOD 30ML Functions
APPENDIX A - ASSIGNMENT STATEMENT REFERENCE
Table A-2. Assignment statements of type 'display_resource = source_name' (ex. #LINE1 = I1)
Resource Format Displayed Result
#LBAR Discrete: None off, segment 1 on
#MBAR Bar 0 - 50 segments on (lo_limit - hi_limit), 50 segments on (> hi_limit)
#RBAR Dev
Short_state: None 0 - 15 segments on
Bar 0 - 50 segments on (lo_limit - hi_limit), 50 segments on (> hi_limit)
Dev
Long_state: None 0 - 50 segments on (0 - 50), 50 segments on (51 - 255)
Bar 0 - 50 segments on (lo_limit - hi_limit), 50 segments on (> hi_limit)
Dev
Count: None 0 - 50 segments on (0 - 50), 50 segments on (51 - 65535)
Bar 0 - 50 segments on (lo_limit - hi_limit), 50 segments on (> hi_limit)
Dev
Msec_time: None 0 - 50 segments on (00:00:00.000 - 00:00:00.050), 50 segments on
(00:00:00.051 and up)
Bar 0 - 50 segments on (lo_limit - hi_limit), 50 segments on (> hi_limit)
Dev
Floating_point None 0 - 50 segments on (0.0 - 50.0), 50 segments on (51.0 and up)
Bar 0 - 50 segments on (lo_limit - hi_limit), 50 segments on (> hi_limit)
Dev
DEV format is not valid for intensified segments and causes a 'INVALID DISP OP' diagnostic
#LISEGn Discrete: None off, segment 1 on
#MISEGn Bar off (< lo_limit), one of segments 1 - 50 on (lo_limit - hi_limit), segment 50 on
(> hi_limit)
#RISEGn Short_state: None off (0), one of segments 1 - 15 on (1 - 15)
Bar off (< lo_limit), one of segments 1 - 50 on (lo_limit - hi_limit), segment 50 on
(> hi_limit)
Long_state: None off (0), one of segments 1 - 50 on (1 - 50), segment 50 on (51 - 255)
Bar off (< lo_limit), one of segments 1 - 50 on (lo_limit - hi_limit), segment 50 on
(> hi_limit)
Count: None off (0), one of segments 1 - 50 on (1 - 50), segment 50 on (51 - 65535)
Bar off (< lo_limit), one of segments 1 - 50 on (lo_limit - hi_limit), segment 50 on
(> hi_limit)
Msec_time: None off (0), one of segments 1 - 50 on (00:00:00.001 - 00:00:00.050), segment 50
on (00:00:00.051 and up)
Bar off (< lo_limit), one of segments 1 - 50 on (lo_limit - hi_limit), segment 50 on
(> hi_limit)
Floating_point None off (0.x), one of segments 1 - 50 on (1.0 - 50.0), segment 50 on (51.0 and up)
Bar off (< lo_limit), one of segments 1 - 50 on (lo_limit - hi_limit), segment 50 on
(> hi_limit)
#LED Discrete: na off, on
#BEEPER Short_state: na off (0), on (1), system use (2 - 15)
Long_state: na off (0), on (1), system use (2 - 255)
Count: na off (0), on (1), system use (2 - 65535)
Msec_time: na off (00:00:00.000), on (00:00:00.001), system use (00:00:00.002 and up)
Floating_point na off (0.x), on (1.x), system use (2.0 and up)
#UPDN Discrete: na off, up arrow on
Short_state: na dn arrow, slash and up arrow show binary value (0 - 7), system use (8 - 15)
Long_state: na dn arrow, slash and up arrow show binary value (0 - 7), system use (8 - 255)
Count: na dn arrow, slash and up arrow show binary value (0 - 7), system use (8 -
65535)
Msec_time: na dn arrow, slash and up arrow show binary value (0 - 00:00:00.007), system
use (00:00:00.008 and up)
Floating_point na dn arrow, slash and up arrow show binary value of integer part (0.x - 7.x),
system use (8.0 and up)
A-5
