Gamatronic Electronic Industries Ltd.

POWER+ RM100,

3

X

208

V, User Guide, Release 2.7ys

71

Note: The data displayed in Figure 96 depends on the options installed and configured. See

Figure 162 on page 96 and Figure 198 on page 107.

10. View status of the fuses:

[Main Menu > SYSTEM >

▼ ▼ ▼ ▼ ▼ ▼]

BATT FUSE: BAD EMERGENCY: OPEN
USER-1: OPEN USER-4: OPEN
USER-2: OPEN 7: OPEN
USER-3: OPEN 8: OPEN

Figure 97: Fuse status

11. View communication with the converter in the transmit mode (for Technicians):

[Main Menu > SYSTEM >

▼ ▼ ▼ ▼ ▼ ▼ ▼]

PD DIALOG: UPS #01
T>c0 42 00 00 d8 00 00 00 00 00 00 00 00
00 00 00 00 00 00 aa

Figure 98: Communication with inverter – transmit

12. View communication with the converter in the receive mode (for Technicians):

[Main Menu > SYSTEM >

▼ ▼ ▼ ▼ ▼ ▼ ▼ ►]

R 1074 2f37 5362 0000 0200 0100 0310
f077 0000 0000 0000 0000 0000 0000
0000 0000 0000 0000 52 52

Figure 99: Communication with inverter – receive

13. Press

Ent to return to the Main Menu (Figure 86 on page 67).
