E-24-
POSITIONER 1067 4 OPERATION
X-LIMIT Limitation of mechanical range
- XMIN - Input of initial value of stroke range in %.
- XMAX - Input of final value of stroke range in %
X-TIME Limitation of correcting time
- OPN FAST - No limitation of correcting time during opening
- OPN SLOW - Limitation of correcting time during opening
- CLS FAST - No limitation of correcting time during closing
- CLS SLOW - Limitation of correcting time during closing
PCONTRL Process controller configuration
- SETPOINT - Method of presetting desired value
INTERN Desired value preset internally via keys
EXTERN Desired value preset externally via signal input
- PARAM - Process controller parameters
KP Proportional correction value
TN Reset time
TV Rate time
X0 Operating point
DBD No sensibility range of the process controller
- SCALE - Scalling input and setpoint values
DP Position of decimal point
PV-L Lower scale value for process quantity
PV-H Upper scale value for process quantity
SP-L Lower scale value for setpoint (only for SETPOINT EXTERN)
SP-H Upper scale value for setpoint (only for SETPOINT EXTERN)
BIN-IN Operation of binary input.
- INACTIVE - Binary input inactive
- SAFEPOS - Safety position
SPOS Position in %
- NORM OPN - Binary input open, if not active (closed)
- NORM CLS - Binary input closed, if not active (open)
OUTPUT Output configuration (option)
- ANALOG - Analog or process position feedback
- BINARY - Programmable Binary output
XDO Control value deviation alarm
XD Limit value of admissible control value deviation
NORM OPN Binary output normally open
NORM CLS Binary output normally closed
BOOST - Signal output for external Booster valve
CODE 4 Positions user code
- MENU+M/A Protection code for all operating functions
- MENU+M/A Protection code for configuration menus
