E-8-
POSITIONER 1067
2 DESCRIPTION
2.5 Technical data
Electrical data
Power supply:
24 VDC ±10%, residual ripple 10%, No industrial DC
Power consumption:
< 10 W
Input for desired value
Input for setpoint for position or process control:
- Unit signal
4 ... 20 mA
- Unit signal
0 ... 20 mA
- Unit signal
0 ... 10 V
Input for process signal (in case of process control):
- Unit signal
4 ... 20 mA
Binary input:
Can be configured as a normally open or normally
closed
contact.
Terminations: 1.5
mm
2
bolted terminals
Two cable glands
Pneumatic data
Control medium:
filtered compressed dry air, oiled or non-oiled
Dust content
class 4,
max. particle size 15 µm,
max. particle density 8 mg/m
3
Dew point
class 4 (+3 °C)
Oil content
class 5, max. 25 mg/m
3
Pressure range:
0 ... 6 bar
Air rates
Inlet valve:
23 Nl / min
(1)
Exhaust valve:
25 Nl / min
(1)
Air consumption by unit
in stable state:
0 Nl / min
Unions:
G 1/8" internal thread
(1)
When pressure reduction from 6 to 5 bar
Mechanical data
Regulation range of internal path-measuring system:
lift turn: 10...80 mm
rotary movement: 0...180°
Regulation range of external path-measuring system:
lift turn: 0...50 mm
Process controller data
Proportional correction value KP:
0...99,99
Reset time TN:
0.5...999.9
Rate time TV:
0.0...999.9
Operating point:
0...100%
Installation and operating data
External dimensions of positioner :
125 mm x 80 mm x 80 mm (W x H x D)
Material of body:
Aluminium, lacquered
Material of the fluid plate:
Aluminium, anodised
Weight of positioner:
Approx. 1 kg
Degree of protection:
IP 65
Operating temperature:
0 ... 60 °C
