FunctionsoftheConfigurationLevel
12.15.4. error messages for B_O1 and B_O2
B_O1 B_O2 description
ERR1 ERR3
ERR1 is displayed if the process value displayed by the monitoring window is
exceeded or not reached relatively to the set-point value
(PV >
SETP+HYHI or PV < SETP-HYLO).
The last measurement value is displayed and the red LED is lit.
According to the definition made in
B_O1, the binary output is set to LOW (0 V) or
HIGH (24 V).
The controller remains active.
RESET: The red LED goes off. The display and the binary output are reset automati-
cally as soon as the process value displayed in the monitoring window is once again
within the range of the set-point value.
ERR2 ERR4
ERR2 is displayed if the value displayed by the monitoring window is exceeded or
not reached absolutely to the fixed process value limit (
PVHI, PVLO).
(PV > PVHI or PV < PVLO).
The last measurement value is displayed and the red LED is lit.
According to the definition made in
B_O1, the binary output is set to LOW (0 V) or
HIGH (24 V).
The controller remains active.
RESET: The red LED goes off. The display and the binary output are reset automati-
cally as soon as the process value displayed in the monitoring window is once again
within the process value limit.
Table 34: B_O1; error messages
12.16. B_O2 - second binary output
The binary output B_O2 is only available for the control cabinet model of Type 8611.
The description for binary output B_O2 is identical to that of binary output B_O1 (see chapter 12.15).
As all models of the eCONTROL Type 8611 controller are equipped with the same software, the B_O2
menu option also exists in the assembly models for wall, rail, valve and fitting assembly, even though binary
output B_O2 is not available.
If B_02 is activated, an error message is displayed on the display or by the LED in accordance with the
defined limit values.
