29
OperationandFunction
9.3. function of the keys
The device is operated using two arrow keys and one ENTER key.
The function of these in respect of the operating level and the operating state is shown in Table 12
below.
Operating
level Operating
state
Level 1:
Process
operating level
AUTOMATIC
Switch display between actual value,
set-point value and manipulated
variable
• Press key briefly (< 1 s):
Switches to operating state MANUAL
• Press and hold key (> 5 s):
Switches to configuration level
MANUAL
Switches to the
last menu option Switches to the
next menu option
• Selection of menu option
• Take over settings
• Switches to operating state AUTO-
MATIC (for display BACK)
Entering of values
Increase value
Change by one
position to the left
Level 2:
Configuration
level
Switches to the
last menu option Switches to the
next menu option • Selection of menu option
• Take over settings
• Switches to process operating level
and to operating state AUTOMATIC
(for display
END)
Entering of values
Increase value
Change by one
position to the left
Table 12: Function of the keys
