TechnicalData
6.5. electrical data
Operating voltage: 24 V DC ±10 %, filtered and controlled
Power consumption without load: approx. 2 W
with load: maximum 48 W
100 % ED: 36 W
Controller sampling rate: 300 Hz
6.5.1. inputs
set-point value
Standard 4 - 20 mA Input impedance: 70 Ω
Resolution: 5.5 µA
Standard 0 - 10 V Input impedance: 11.5 kΩ
Resolution: 2,5 mV
sensors
Standard 4 - 20 mA Input impedance: 70 Ω
Resolution: 5.5 µA
Frequency
Input 1 External sensor
Frequency range:
min. 0.25 Hz / max. 1 kHz
Input resistance: > 1 kΩ
Signal types: Sine, rectangle, triangle (> 3000 mVss,
max. 30 Vss)
Input 2 Internal Hall sensor
Frequency range:
min. 0.25 Hz / max. 1 kHz
(only in conjunction with Bürkert flow-rate fitting
Type S030)
Pt 100 (2-wire) Measuring range: 0 °C ... 200 °C
Measured current: 1 mA
Measuring error: < 0.5 °C
Binary input Input impedance: 10 kΩ
Response threshold: 3 ... 30 V
Max. frequency: 1 kHz
