Dynasonics TFXP Series Transit Time Ultrasonic Flow Meter User Manual
Page 4
Rev. 5/09
-1.2-
TFXP
TABLE OF CONTENTS
Pages
Quick-Start Operating Instructions
1.4 - 1.6
Introduction
General
1.7
Applications
1.7
Product Matrix
1.8
Product Specifications
1.9
Transmitter Connections
1.10 - 1.11
Battery Charging and Maintenance
1.12 - 1.13
Input/Output Connections and Options
4-20 mA Output
1.14
Optional Data Logger
1.15
Other Optional ISO-MODs
1.15
General
2.1
Mounting Location
2.2 - 2.3
Transducer Spacing
2.4 - 2.7
Transducer Mounting, Pipe Preparation
2.8 - 2.9
Transducer Mounting, V-Mount and W-Mount
2.9 - 2.11
Transducer Mounting, DTTH High Temp
2.12
Transducer Mounting, DTTS/DTTC Small Pipe
2.12 - 2.13
Transducer Mounting, Z-Mount
2.13 - 2.15
Mounting Track Installation
2.16 - 2.17
RTD Installation
2.18 - 2.20
General Programming Information
3.1 - 3.4
Startup and Configuration
3.1
Part 1 -
Introduction
Connections
Inputs and
Outputs
Part 2 -
Transducer
and RTD
Installation
Part 3 -
Operation
