Model lsb – Xylem LSB User Manual
Page 98
Installation, Operation and Maintenance Instruction
Model LSB
LSB 100-english
page 94
Revision 02
Artikel Nr. 771076129
Ausgabe 01/2010
Adjust the face on the impeller side of the mech.
seal exactly on measure A. For mech. seals
without own set screws the fixing ring (527) serves
as a stop.
Push mech. seals with bellows in such a way,
that the bellow is compressed and not stretched
(danger of tearing apart!).
Use anti-friction device (Molykote, etc.) between
shaft sleeve and shaft only, if you are sure that
no dangerous reactions between pumped liquid
and anti-friction device can occur.
Further assembly and installation of pump acc.
chapter 8 of Installation, Operation and
Maintenance Instruction.
Before starting the pump connect flushing
system for quench and put it into operation.
