6: Spectrometer Menu Functions
000-20000-300-02- 201110 75
Feature Meaning
Show Raw
Brightness/Contrast
Reset Displays the raw image.
Adjust the brightness/contrast of the image.
Resets the brightness and contrast to the dafault (middle of scale)
Save
Save Raw Image/Processed Image
Save Raw Data as Text
Transpose
Save the raw/processed image to a jpg, png, gif, bmp or x-png file.
Save the raw a data as a text file.
Transpose the image.
Save Raw Data as Text Save the raw data as a text file.
Zoom Standard controls to zoom in/out
Advanced Displays a dialog box. See for more information.
Advanced Image Dialog Box
The Advanced Image button allows you can access even more features of the image seen by the detector
as shown in the examples below.
Auto Equalize Disabled
Auto Equalize Enabled
False Color Spectrum – Provides a legend for the coloration of the transformed gray-scale detector
image shown just below the legend.
