3: Controls and Indicators
000-20000-300-02- 201110 25
Layer Tools
The Layer tools provide you with functions to write captions and other meaningful data on your graphs.
Select the tools using the Layer Toolbar.
Tool Function
Add New Annotation. Displays the New Annotation dialog box to add a new annotation to
the selected graph.
Select and Drag Annotation. Allows you to grab an annotation on the graph and drag it to
another location.
Draw. Allows you to draw freehand (using the mouse) on the graph.
Erase Areas of Drawing Layer. Erases selected portions of the drawing created with the
Draw tool (pencil).
