Xerox 785 User Manual
Page 326
B-36
WorkCentre Pro 665/685/765/785
9.
Holding the Developer Assembly by the green handles, align the
three shafts on the Developer Assembly sides with the slots in
the machine frame. Lower the assembly into the machine.
The following figure shows how the shafts on the Developer
Assembly align with the slots.
Developer
027
Assembly
028
