Position the Drum Unit with the green drum surface facing the
black toner roller on the Developer Assembly. Without touching
the green drum surface, hook the Drum Unit to the Developer
Assembly. The following figure shows how to join the Drum Unit
and the Developer Assembly.
Drum Unit
026
Developer
Assembly
