Xerox 785 User Manual
Page 318
B-28
WorkCentre Pro 665/685/765/785
10. Position the Drum Unit with the green drum surface facing the
black roller on the Developer Assembly. Without touching the
green drum surface, hook the Drum Unit to the Developer
Assembly. The following figure shows how to join the Drum Unit
and the Developer Assembly.
026
Drum Unit
Developer
Assembly
