Xerox 785 User Manual
Page 299
WorkCentre Pro 665/685/765/785
B-9
14. Position the Drum Unit with the green drum surface facing the
black toner roller on the Developer Assembly. Without touching
the green drum surface, hook the Drum Unit to the Developer
Assembly. The following figure shows how to join the Drum Unit
and the Developer Assembly.
Drum Unit
Developer
Assembly
026
