Reports
WorkCentre Pro 665/685/765/785
9-3
* The Code is displayed in 3 digits to the right of the Mode symbol.
Mode
Communication mode*
t
:
2nd Line Communication
EX: Exclusive Error Control Mode
G3: G3 Mode
EC: G3 Error Control Mode
P:
Polling Communications
R: Relay
Group
Communications
B: Mailbox
Communications
SB:
Subaddress Communication
Code
Transmission
Speed
Code Line Density
Code
Encoding
0
2400 bps
0
8 pels/mm x 3.85 lines/mm
0
MH
1
4800 bps
1
8 pels/mm x 7.7lines/mm
1
MR
2
7200 bps
2
8 pels/mm x 15.4 lines/mm
2
MMR
3
9600 bps
3
—
3
JBIG
4
12000 bps
4
16 pels/mm x 15.4 lines/mm
5
14400 bps
6
33600 bps
Item
Description
Status
Result status of communication and error codes.
OK - Successful
NG - Failure
See Chapter 15 for error code list.
Item
Description
G3
Encoded Data
Line Density Data
Transmission Speed
G3
MMR
8 pels/mm x 3.85/lines/mm
14400 bps
5 0 2
Example:
CODE
