Troubleshooting
16-18 WorkCentre Pro 665/685/765/785
Status Code Table
A status code is displayed on some reports. The Code is displayed in
3 digits to the right of the Mode symbol.
Code
Transmission
Speed
Code Line Density Code Encoding
0 2400 bps 0 8 pels/mm x 3.85 lines/mm 0 MH
1 4800 bps 1 8 pels/mm x 7.7lines/mm 1 MR
2 7200 bps 2 8 pels/mm x 15.4 lines/mm 2 MMR
3 9600 bps 3 — 3 JBIG
4 12000 bps 4 16 pels/mm x 15.4 lines/mm
5 14400 bps
6 33600 bps
G3
Encoded Data
Line Density Data
Transmission Speed
G3
MMR
8 pels/mm x 3.85/lines/mm
14400 bps
5 0 2
Example: CODE
