B-8 WorkCentre Pro 665/685/765/785
11. Align the four hooks on the new Toner Cartridge with the slots on
the Developer Assembly. Fit the cartridge to the assembly. The
following figure shows how the Toner Cartridge and the
Developer Assembly connect.
12. Move the cartridge to the right until the button on the left of the
Developer Assembly clicks into place.
13. Holding the Developer Assembly with one hand, grasp the edge
of the protective strip under the toner housing. Pull the Strip firmly
to completely remove it from the cartridge.
Toner Cartridge
Developer
096 Assembly
Strip
Developer
025
Assembly
