Chapter 3 Hardware Overview
XGS-4728F User’s Guide
40
3.2.2 External Backup Power Supply Connector
The Switch supports external backup power supply (BPS).
The Switch constantly monitors the status of the internal power supply. The
backup power supply automatically provides power to the Switch in the event of a
power failure. Once the Switch receives power from the backup power supply, it
will not automatically switch back to using the internal power supply even when
the power is resumed.
3.2.3 Console Port
For local management, you can use a computer with terminal emulation software
configured to the following parameters:
• VT100 terminal emulation
• 9600 bps
• No parity, 8 data bits, 1 stop bit
• No flow control
Connect the male 9-pin end of the RS-232 console cable to the console port of the
Switch. Connect the female end to a serial port (COM1, COM2 or other COM port)
of your computer.
3.3 LEDs
The following table describes the LEDs.
Table 3 LEDs
LED
COLO
R
STATUS DESCRIPTION
BPS Green Blinking The system is receiving power from the backup power
supply.
On The backup power supply is connected and active.
Off The backup power supply is not ready or not active.
PWR Green On The system is turned on.
Off The system is off.
SYS Green Blinking The system is rebooting and performing self-diagnostic
tests.
On The system is on and functioning properly.
Off The power is off or the system is not ready/
malfunctioning.
