Chapter 20 Classifier
XGS-4728F User’s Guide
175
Layer 2
Specify the fields below to configure a layer 2 classifier.
VLAN
Select Any to classify traffic from any VLAN or select the second option and
specify the source VLAN ID in the field provided.
Priority
Select Any to classify traffic from any priority level or select the second option
and specify a priority level in the field provided.
Ethernet
Type
Select an Ethernet type or select Other and enter the Ethernet type number in
hexadecimal value. Refer to
for information.
Source
MAC
Address
Select Any to apply the rule to all MAC addresses.
To specify a source, select the second choice and type a MAC address in valid
MAC address format (six hexadecimal character pairs).
Port
Type the port number to which the rule should be applied. You may choose one
port only or all ports (Any).
Destination
MAC
Address
Select Any to apply the rule to all MAC addresses.
To specify a destination, select the second choice and type a MAC address in
valid MAC address format (six hexadecimal character pairs).
Layer 3
Specify the fields below to configure a layer 3 classifier.
DSCP
Select Any to classify traffic from any DSCP or select the second option and
specify a DSCP (DiffServ Code Point) number between 0 and 63 in the field
provided.
IP
Protocol
Select an IP protocol type or select Other and enter the protocol number in
decimal value. Refer to
for more information.
You may select Establish Only for TCP protocol type. This means that the
Switch will pick out the packets that are sent to establish TCP connections.
Source
IP
Address/
Address
Prefix
Enter a source IP address in dotted decimal notation.
Specify the address prefix by entering the number of ones in the subnet mask.
Socket
Number
Note: You must select either UDP or TCP in the IP Protocol field before
you configure the socket numbers.
Select Any to apply the rule to all TCP/UDP protocol port numbers or select
the second option and enter a TCP/UDP protocol port number.
Destination
IP
Address/
Address
Prefix
Enter a destination IP address in dotted decimal notation.
Specify the address prefix by entering the number of ones in the subnet mask.
Table 48 Advanced Application > Classifier (continued)
LABEL
DESCRIPTION
