ZyXEL Communications XGS-4728F - Manual (Page 336)

Chapter 39 Access Control
XGS-4728F User’s Guide
336
39.3.3 SNMP Traps
The Switch sends traps to an SNMP manager when an event occurs. The following
tables outline the SNMP traps by category.
An OID (Object ID) that begins with “1.3.6.1.4.1.890.1.5.8.” is defined in private
MIBs. Otherwise, it is a standard MIB OID.
The OIDs beginning with “1.3.6.1.4.1.890.1.5.8. 46 ” are specific to the XGS-
4728F switch.
Table 125 SNMP System Traps
OPTION OBJECT LABEL OBJECT ID DESCRIPTION
coldstart coldStart 1.3.6.1.6.3.1.1.5.1 This trap is sent when the
Switch is turned on.
warmstart warmStart 1.3.6.1.6.3.1.1.5.2 This trap is sent when the
Switch restarts.
fanspeed FanSpeedEventOn 1.3.6.1.4.1.890.1.5.8.46.3
1.2.1 This trap is sent when the fan
speed goes above or below the
normal operating range.
FanSpeedEventClear 1.3.6.1.4.1.890.1.5.8.46.3
1.2.2 This trap is sent when the fan
speed returns to the normal
operating range.
temperatur
e TemperatureEventOn 1.3.6.1.4.1.890.1.5.8.46.3
1.2.1 This trap is sent when the
temperature goes above or
below the normal operating
range.
TemperatureEventClear 1.3.6.1.4.1.890.1.5.8.46.3
1.2.2 This trap is sent when the
temperature returns to the
normal operating range.
voltage VoltageEventOn 1.3.6.1.4.1.890.1.5.8.46.3
1.2.1 This trap is sent when the
voltage goes above or below the
normal operating range.
VoltageEventClear 1.3.6.1.4.1.890.1.5.8.46.3
1.2.2 This trap is sent when the
voltage returns to the normal
operating range.
reset UncontrolledResetEventOn 1.3.6.1.4.1.890.1.5.8.46.3
1.2.1
This trap is sent when the
Switch automatically resets.
ControlledResetEventOn 1.3.6.1.4.1.890.1.5.8.46.3
1.2.1 This trap is sent when the
Switch resets by an
administrator through a
management interface.
RebootEvent 1.3.6.1.4.1.890.1.5.1.1.2 This trap is sent when the
Switch reboots by an
administrator through a
management interface.
