Chapter 31 RIP
XGS-4728F User’s Guide
272
automatically created when you configure a new IP domain in the IP Setup
screen (refer to
Figure 145 IP Application > RIP
The following table describes the labels in this screen.
Table 93 IP Application > RIP
LABEL
DESCRIPTION
Active
Select this check box to enable RIP on the Switch.
Index
This field displays the index number of an IP interface.
Network This field displays the IP interface configured on the Switch.
Refer to the section on IP Setup for more information on configuring IP
domains.
Directio
n
Select the RIP direction from the drop-down list box. Choices are Outgoing,
Incoming, Both and None.
Version
Select the RIP version from the drop-down list box. Choices are RIP-1, RIP-
2B and RIP-2M.
Apply
Click Apply to save your changes to the Switch’s run-time memory. The Switch
loses these changes if it is turned off or loses power, so use the Save link on
the top navigation panel to save your changes to the non-volatile memory
when you are done configuring.
Cancel
Click Cancel to begin configuring this screen afresh.
