Chapter 43 MAC Table
XGS-4728F User’s Guide
369
The following table describes the labels in this screen.
Table 143 Management > MAC Table
LABEL
DESCRIPTION
Condition
Select All to display all MAC addresses in the MAC table.
Select Static to only display static MAC address(es) in this screen.
Select MAC and enter a valid MAC address (six hexadecimal character
pairs) to display the MAC address information in this screen.
Select VID and type a VLAN identification number to display all MAC
addresses in the VLAN.
Select Port and type the number of a port to display all MAC addresses
learned from the port.
Sort by
Select this to display and arrange the data according to MAC address
(MAC), VLAN group (VID) or port number (Port). The information is then
displayed in the summary table below.
Transfer Type Select Dynamic to MAC forwarding and click Transfer to add the
relative dynamic MAC address(es) you select the criteria here into the
static MAC forwarding table (see
). The type of
the MAC address(es) will be changed to “static”.
Select Dynamic to MAC filtering and click Transfer to add the relative
dynamic MAC address(es) you make the search here into the static MAC
filtering table (see
). The MAC address(es) will
be removed from the MAC table and all traffic sent from the MAC
address(es) will be blocked by the Switch.
Search
Click this to search data in the MAC table according to your input criteria.
Transfer
Click this to perform the MAC address transferring you selected in the
Transfer Type field.
Cancel
Click this to begin configuring the search criteria afresh.
Index
This is the incoming frame index number.
MAC Address This is the MAC address of the device from which this incoming frame
came.
VID
This is the VLAN group to which this frame belongs.
Port
This is the port from which the above MAC address was learned.
Type
This shows whether the MAC address is dynamic (learned by the Switch)
or static (manually entered in the Static MAC Forwarding screen).
