Chapter 49 Product Specifications
XGS-4728F User’s Guide
394
LEDs Main switch: BPS, PWR, SYS, ALM,
Per Stacking port: S1, S2
Per mini-GBIC port: green LED
Per 1000Base-T port:
Green: 10/1000 Mbps
Amber: 100 Mbps
mini-GBIC/1000Base-T LEDs:
steady: link state
blinking: transmitting/receiving
Operating
Environment Temperature: 0º C ~ 45º C (32º F ~ 113º F)
Humidity: 10 ~ 90% (non-condensing)
Storage Environment Temperature: -10º C ~ 70º C (-13º F ~ 158º F)
Humidity: 10 ~ 90% (non-condensing)
Ground Wire Gauge 18 AWG or larger
Power Wire Gauge 18 AWG or larger
Fuse Specification 250 VAC, T4A. For DC version switchboard.
Approvals Safety
UL 60950-1, CSA 60950-1, EN 60950-1, IEC 60950-1
EMC
FCC Part 15 (Class A), CE EMC (Class A)
Table 152 Firmware Specifications
FEATURE DESCRIPTION
Default IP Address In band: 192.168.1.1
Out of band (Management port): 192.168.0.1
Default Subnet Mask 255.255.255.0 (24 bits)
Administrator User
Name admin
Default Password 1234
Number of Login
Accounts Configurable
on the Switch 4 management accounts configured on the Switch.
Authentication via RADIUS and TACACS+ also available.
IP Routing Domain An IP interface (also known as an IP routing domain) is not
bound to a physical port. Configure an IP routing domain to
allow the Switch to route traffic between different networks.
Table 151 Hardware Specifications
