Chapter 16 Mirroring
XGS-4728F User’s Guide
152
The following table describes the labels in this screen.
Table 38 Advanced Application > Mirroring
LABEL DESCRIPTION
Active Select this check box to activate port mirroring on the Switch. Clear this check
box to disable the feature.
Monitor
Port The monitor port is the port you copy the traffic to in order to examine it in
more detail without interfering with the traffic flow on the original port(s).
Type the port number of the monitor port.
Port This field displays the port number.
* Settings in this row apply to all ports.
Use this row only if you want to make some settings the same for all ports.
Use this row first to set the common settings and then make adjustments on
a port-by-port basis.
Note: Changes in this row are copied to all the ports as soon as you
make them.
Mirrored Select this option to mirror the traffic on a port.
Direction Specify the direction of the traffic to mirror by selecting from the drop-down
list box. Choices are Egress (outgoing), Ingress (incoming) and Both.
Apply Click Apply to save your changes to the Switch’s run-time memory. The
Switch loses these changes if it is turned off or loses power, so use the Save
link on the top navigation panel to save your changes to the non-volatile
memory when you are done configuring.
Cancel Click Cancel to begin configuring this screen afresh.
