Chapter 32 OSPF
XGS-4728F User’s Guide
276
3
Create and associate interface(s) to an area
4
Create virtual links to maintain backbone connectivity.
32.2 OSPF Status
Use this screen to view current OSPF status. Click IP Application > OSPF in the
navigation panel to display the screen as shown next. See
Section 32.1 on page
273 for more information on OSPF.
Figure 148 IP Application > OSPF Status
The following table describes the labels in this screen.
Table 96 IP Application > OSPF Status
LABEL DESCRIPTION
OSPF This field displays whether OSPF is activated (Running) or not (Down).
Interface The text box displays the OSPF status of the interface(s) on the Switch.
Neighbor The text box displays the status of the neighboring router participating in
the OSPF network.
Link State
Database The text box displays information in the link state database which contains
data in the LSAs.
