Chapter 32 OSPF
XGS-4728F User’s Guide
277
The following table describes some common output fields.
Poll
Interval(s) The text box displays how often (in seconds) this screen refreshes. You
may change the refresh interval by typing a new number in the text box
and then clicking Set Interval.
Stop Click Stop to end OSPF status polling.
Table 97 OSPF Status: Common Output Fields
FIELD DESCRIPTION
Interface
Internet
Address
This field displays the IP address and subnet bits of an IP routing
domain.
Area This field displays the area ID.
Router ID This field displays the unique ID of the Switch.
Transmit Delay This field displays the transmission delay in seconds.
State
This field displays the state of the Switch (backup or DR (designated
router)).
Priority This field displays the priority of the Switch. This number is used in the
designated router election.
Designated
Router This field displays the router ID of the designated router.
Backup
Designated
Router This field displays the router ID of a backup designated router.
Time Intervals
Configured This field displays the time intervals (in seconds) configured.
Neighbor Count This field displays the number of neighbor routers.
Adjacent
Neighbor Count
This field displays the number of neighbor router(s) that is adjacent to
the Switch.
Neighbor
Neighbor ID
This field displays the router ID of the neighbor.
Pri This field displays the priority of the neighbor. This number is used in
the designated router election.
State This field displays the state of the neighbor (backup or DR (designated
router)).
Dead Time This field displays the dead time in seconds.
Address This field displays the IP address of a neighbor.
Interface This field displays the MAC address of a device.
Link State Database
Link ID
This field displays the ID of a router or subnet.
ADV Router This field displays the IP address of the layer-3 device that sends the
LSAs.
Age This field displays the time (in seconds) since the last LSA was sent.
Table 96 IP Application > OSPF Status (continued)
LABEL DESCRIPTION
