Chapter 17 Link Aggregation
XGS-4728F User’s Guide
159
17.5 Link Aggregation Control Protocol
Click in the Advanced Application > Link Aggregation > Link Aggregation
Setting > LACP to display the screen shown next. See
Section 17.2 on page 153
for more information on dynamic link aggregation.
Figure 81 Advanced Application > Link Aggregation > Link Aggregation Setting >
LACP
The following table describes the labels in this screen.
Table 43 Advanced Application > Link Aggregation > Link Aggregation Setting >
LACP
LABEL DESCRIPTION
Link
Aggregation
Control
Protocol
Note: Do not configure this screen unless you want to enable
dynamic link aggregation.
Active Select this checkbox to enable Link Aggregation Control Protocol (LACP).
