Apx.C Pin Assignments Appendices
Satellite Pro M10 Series Maintenance Manual (960-431) C-33
C.35 PJ5007 System Board (FQDSY*) I/F Connector (60-pin)
Table C-35 System board (FQDSY*) I/F connector pin assignments (60-pin)
Pin No. Signal name I/O Pin No. Signal name I/O
1 CDAUDL-EXP I 2 CD-GND -
3 CDAUDR-EXP I 4 CD-GND -
5 DINL-PXN I 6 DINL-PXP I
7 DINR-PXP I 8 DINR-PXN I
9 GND - 10 X97BCK-P3P O
11 GND - 12 M97SY1-P3P I
13 M97RS1-S3N I 14 GND -
15 M97OT1-P3P I 16 M97IN1-P3P O
17 GND - 18 X14SND-P3P I
19 GND - 20 ATBEEP-B3P I
21 PVON-S5P I 22 NC -
23 P3V I 24 P3V I
25 NC - 26 SND-E5V I
27 SND-E5V I 28 SND-E5V I
29 SND-E5V I 30 SND-E5V I
31 SND-GND - 32 OZPVEN-S3N I
33 SND-GND - 34 PHONE-BXP I
35 PHONE-BXN I 36 SND-GND -
37 DOUTL-PXN O 38 DOUTL-PXP O
39 SND-GND - 40 DOUTR-PXN O
41 DOUTR-PXP O 42 SND-GND -
43 SNDMUT-S3N I 44 AMPSD-S3N I
45 SND-GND - 46 CAUDIO-B3P I
47 SND-GND - 48 SPKOTR-EXP O
49 SPKOTR-EXP O 50 SPKOTR-EXN O
51 SPKOTR-EXN O 52 SPKOTL-EXP O
53 SPKOTL-EXP O 54 SPKOTL-EXN O
55 SPKOTL-EXN O 56 SND-GND -
57 SND-GND - 58 SND-GND -
59 SND-GND - 60 SND-GND -
