Apx.C Pin Assignments Appendices
Satellite Pro M10 Series Maintenance Manual (960-431) C-21
C.14 PJ2017 MDC I/F Connector (30-pin)
Table C-14 MDC I/F connector pin assignments (30-pin)
Pin No. Signal name I/O Pin No. Signal name I/O
1 NC - 2 GND -
3 GND - 4 PHONE-BXN O
5 NC - 6 NC -
7 NC - 8 GND -
9 NC - 10 NC -
11 NC - 12 NC -
13 NC - 14 NC -
15 GND - 16 MDC-B3V O
17 MDC-B3V O 18 NC -
19 GND - 20 GND -
21 NC - 22 M97SY2-P3P O
23 M97OT2-P3P O 24 NC -
25 -M97RS2-S3N O 26 M97IN2-B3P I
27 GND - 28 GND -
29 GND - 30 X97BMD-P3P I/O
C.15 PJ2018 Modem Cable I/F Connector (2-pin)
Table C-15 Modem Cable I/F connector pin assignments (2-pin)
Pin No. Signal name I/O Pin No. Signal name I/O
1 MDMTIP-B3P I/O 2 MDMRNG-B3P I/O
