Appendices Apx.C Pin Assignments
C-4 Satellite Pro M10 Series Maintenance Manual (960-431)
C.2 PJ117 Slim Select Bay I/F Connector (72-pin)
Table C-2 Slim Select Bay I/F connector pin assignments (72-pin)
Pin No. Signal name I/O Pin No. Signal name I/O
1 GND - 2 GND -
3 CDAUDR-EXP O 4 CDAUDL-EXP O
5 GND - 6 CD-GND -
7 IDRSTB-E5N O 8 GND -
9 GND - 10 SDD07-E5P I/O
11 SDD08-E5P I/O 12 SDD06-E5P I/O
13 SDD09-E5P I/O 14 SDD05-E5P I/O
15 SDD10-E5P I/O 16 GND -
17 GND - 18 SDD04-E5P I/O
19 SDD11-E5P I/O 20 SDD03-E5P I/O
21 SDD12-E5P I/O 22 SDD02-E5P I/O
23 SDD13-E5P I/O 24 SB-E5V O
25 SB-E5V O 26 SDD01-E5P I/O
27 SDD14-E5P I/O 28 SDD00-E5P I/O
29 SDD15-E5P I/O 30 GND -
31 GND - 32 SDDREQ-E5P I
33 GND - 34 SDIOW-E3N O
35 GND - 36 SDIOR-E3N O
37 GND - 38 SIORDY-E5P I
39 NC - 40 SDDACK-E3N O
41 GND - 42 IRQ15-E5P I
43 NC - 44 SDA1-E3P O
45 SB-E5V O 46 SB-E5V O
47 SB-E5V O 48 SDA0-E3P O
49 SDA2-E3P O 50 SDCS1-E3N O
51 SDCS3-E3N O 52 SDASP-E5N I
53 GND - 54 MBSTS2-S3N I
55 MBSTS1-S3N I 56 MBSTS0-S3N I
57 GND - 58 DBT20V-S5N O
59 PSDA-S5P I 60 BT2VD O
61 PSCL-S5P I 62 BTMP2-SXP I
63 CDCHG2-S5P O 64 GND -
65 GND - 66 USBP4-S3N I/O
67 GND - 68 USBP4-S3P I/O
69 GND - 70 GND -
71 GND - 72 PVBAT2 O
