Apx.C Pin Assignments Appendices
Satellite Pro M10 Series Maintenance Manual (960-431) C-17
Table C-12 Docking I/F connector pin assignments (242-pin) (3/4)
Pin No. Signal name I/O Pin No. Signal name I/O
127 GND - 128 DTPB-B3P I/O
129 UBON1D-E5N O 130 UBOC1D-S3N O
131 GND - 132 UBON2D-E5N O
133 UBOC2D-S3N O 134 SNDMUT-S3N O
135 NC - 136 DOUTL-PXP O
137 DINL-PXP - 138 DINR-PXN I
139 GND - 140 PWRSW-S3N I
141 DCD-PYP I 142 DSR-PYP I
143 TXD-PYN O 144 RING-BYP I
145 PE-P5P I 146 PDB07-P5P I/O
147 PDB06-P5P I/O 148 GND -
149 GND - 150 PDB04-P5P I/O
151 PDB01-P5P I/O 152 PDB02-P5P I/O
153 PDB00-P5P I/O 154 STR0B-P5N O
155 NC - 156 NC -
157 GND - 158 NC -
159 NC - 160 NC -
161 GND - 162 NC -
163 NC - 164 NC -
165 GND - 166 NC -
167 NC - 168 NC -
169 GND - 170 NC -
171 NC - 172 NC -
173 GND - 174 NC -
175 LAN-E3V - 176 NC -
177 NC - 178 TERMPL-GND -
179 TXP-EXP O 180 TXN-EXN O
181 DCOUT - 182 DCOUT -
183 DSSDA-S5P I/O 184 IF-P5V -
185 NC - 186 DTPA-B3N I/O
187 GND - 188 DTPB-B3N I/O
189 USBP2D-S3P I/O 190 USBP2D-S3N I/O
191 GND - 192 USBP3D-S3P I/O
193 USBP3D-S3N I/O 194 DOUTR-PXP O
195 DOUTR-PXN O 196 DOUTL-PXN O
197 DINL-PXN I 198 DINR-PXP I
199 GND - 200 RXD-PYN I
