PJ1016 RGB I/F Connector (15-pin)
Table C-8 RGB interface connector pin assignments (15-pin)
Pin No.
Signal name
I/O
Pin No.
Signal name
I/O
1 CRTRED-PXP
O
2 CRTGRN-PXP
O
3 CRTBLU-PXP
O
4 NC
-
5 GND
-
6 GND
-
7 GND
-
8 GND
-
9 P5V
O
10 GND
-
11 NC
-
12 DDCSDA-P5P
I/O
13 HSYNC-B3P
I/O
14 OVSYNC-B3P
I/O
15
DDCSCL-P5P I/O
C.9
PJ1509 HDD I/F Connector (44-pin)
Table C-9 HDD I/F connector pin assignments (44-pin)
Pin No.
Signal name
I/O
Pin No.
Signal name
I/O
1
IDRSTA-P5N O 2
GND -
3
PDD07-P3P I/O 4
PDD08-P3P I/O
5
PDD06-P3P I/O 6
PDD09-P3P I/O
7
PDD05-P3P I/O 8
PDD10-P3P I/O
9
PDD04-P3P I/O
10
PDD11-P3P I/O
11
PDD03-P3P I/O
12
PDD12-P3P I/O
13
PDD02-P3P I/O
14
PDD13-P3P I/O
15
PDD01-P3P I/O
16
PDD14-P3P I/O
17
PDD00-P3P I/O
18
PDD15-P3P I/O
19
GND -
20
NC -
21
PDDREQ-P3P I 22
GND -
23
PDIOW-P3N O
24
GND -
25
PDIOR-P3N O
26
GND -
27
PIORDY-P3P I 28
NC -
29
PDDACK-P3N O 30
GND -
31
IRQ14-P3P I
32
NC -
33
PDA1-P3P O
34
NC -
35
PDA0-P3P O
36
PDA2-P3P O
37
PDCS1-P3N O
38
PDCS3-P3N O
39
HDDLED-P5N I 40
GND -
41
P5V O
42
P5V O
43
GND -
44
NC -
