Appendices

Apx.C Pin Assignments

C-32

Satellite Pro M10 Series Maintenance Manual (960-431)

Sound Board (FQDSD*)
C.32

PJ5000 External Microphone I/F Connector (6-pin)

Table C-32 External microphone I/F connector pin assignments (6-pin)

Pin No.

Signal name

I/O

Pin No.

Signal name

I/O

1 A-GND

2 EMIC-PXP

3 25VREF-P2V

4 A-GND

5 -EMICSL-P5P

6 25VREF-P2V

C.33

PJ5002 Internal Microphone I/F Connector (2-pin)

Table C-33 Internal microphone I/F connector pin assignments (2-pin)

Pin No.

Signal name

I/O

Pin No.

Signal name

I/O

1 IMIC-PXP

I/O

2 A-GND

C.34

PJ5003 Headphone I/F Connector (6-pin)

Table C-34 Headphone I/F connector pin assignments (6-pin)

Pin No.

Signal name

I/O

Pin No.

Signal name

I/O

1 A-GND

2 HEADL-EXP

3 HEADR-EXP

4 A-GND

5 SPKEN-E4P

6 NC
