Appendices Apx.C Pin Assignments
C-20 Satellite Pro M10 Series Maintenance Manual (960-431)
Table C-13 Mini PCI I/F card connector pin assignments (124-pin) (2/2)
Pin No. Signal name I/O Pin No. Signal name I/O
73 CBE1-P3N I 74 GND -
75 AD14-P3P I 76 AD15-P3P O
77 GND - 78 AD13-P3P O
79 AD12-P3P I 80 AD11-P3P O
81 AD10-P3P I 82 GND -
83 GND - 84 AD09-P3P O
85 AD08-P3P I 86 CBE0-P3N O
87 AD07-P3P I 88 P3V O
89 P3V O 90 AD06-P3P O
91 AD05-P3P I 92 AD04-P3P O
93 NC - 94 AD02-P3P O
95 AD03-P3P I 96 AD00-P3P O
97 P5V O 98 NC -
99 AD01-P3P I 100 NC -
101 GND - 102 GND -
103 NC - 104 GND -
105 NC - 106 NC -
107 NC - 108 NC -
109 NC - 110 NC -
111 NC - 112 NC -
113 GND - 114 GND -
115 NC - 116 NC -
117 GND - 118 NC -
119 GND - 120 GND -
121 NC - 122 NC -
123 NC - 124 B3V O
