Apx.C Pin Assignments
Appendices
Satellite Pro M10 Series Maintenance Manual (960-431)
C-7
Table C-6 SO-DIMM socket connector 0 pin assignments (200-pin) (2/3)
Pin No.
Signal name
I/O
Pin No.
Signal name
I/O
63 GND
-
64 GND
-
65 SDQ26R-B2P
I/O
66 SDQ30R-B2P
I/O
67 SDQ27R-B2P
I/O
68 SDQ31R-B2P
I/O
69 2R5-B2V
O
70 2R5-B2V
O
71 SCB5A-B2P
I/O
72 SCB0A-B2P
I/O
73 SCB4A-B2P
I/O
74 SCB1A-B2P
I/O
75 GND
-
76 GND
-
77 SDQS8A-B2P
I/O
78 GND
-
79 SCB2A-B2P
I/O
80 SCB3A-B2P
I/O
81 2R5-B2V
O
82 2R5-B2V
O
83 SCB6A-B2P
I/O
84 SCB7A-B2P
I/O
85 NC
-
86 NC
-
87 GND
-
88 GND
-
89 2R5-B2V
O
90 GND
-
91 GND
-
92 2R5-B2V
O
93 2R5-B2V
O
94 2R5-B2V
O
95 SCKE1-B2P
O
96 SCKE0-B2P
O
97 NC
-
98 NC
-
99
SMA12R-B2P O 100
SMA11R-B2P O
101 SMA09R-B2P
O
102 SMA08R-B2P
O
103 GND
-
104 GND
-
105 SMA07R-B2P
O
106 SMA06R-B2P
O
107 SMA05R-B2P
O
108 SMA04R-B2P
O
109 SMA03R-B2P
O
110 SMA02R-B2P
O
111 SMA01R-B2P
O
112 SMA00R-B2P
O
113 2R5-B2V
O
114 2R5-B2V
O
115 SMA10R-B2P
O
116 SMS1R-B2P
O
117 SBS0R-B2P
O
118 SRASR-B2N
O
119 SWER-B2N
O
120 SCASR-B2N
O
121 SCS0-B2N
O
122 SCS1-B2N
O
123 NC
-
124 NC
-
125 GND
-
126 GND
-
127 SDQ37R-B2P
I/O
128 SDQ33R-B2P
I/O
129 SDQ36R-B2P
I/O
130 SDQ32R-B2P
I/O
131 2R5-B2V
O
132 2R5-B2V
O
133 SDQS4R-B2P
I/O
134 GND
-
135 SDQ34R-B2P
I/O
136 SDQ39R-B2P
I/O
