4.33 TFT FL (Model 15.0 SXGA+ SHARP LQ150F1LH43)
4 Replacement Procedures
Satellite Pro M10 Series Maintenance Manual (960-431)
4-139
10. Turn the LCD module right side up.
11. Remove the LCD panel from the backlight unit. When you remove the LCD panel,
wear finger covers or gloves to avoid contaminating or damaging the LCD panel and
the backlight unit.
LCD panel
Backlight unit
Figure 4-109 Removing the LCD panel
