Appendix B Board Layout
B-2
Satellite Pro M10 Series Maintenance Manual (960-431)
Table B-1 System board (FQDSY*) layout (front) (1/2)
Mark Number
Name
(A)
PJ123
Keyboard I/F Connector
(B)
PJ326
Debug Port I/F Connector
(C)
PJ2003
Touch Pad I/F Connector
(D)
PJ2015
Mini PCI Card I/F Connector
(E)
PJ2025
Switch Board (FQDSQ*) I/F Connector
(F)
PJ4900
Bluetooth I/F Connector
(G)
PJ5004
Right Speaker I/F Connector
(H)
PJ5005
Left Speaker I/F Connector
(I)
PJ5006
Sound Board (FQDSD*) I/F Connector
(J)
PJ8770
Cooling fan I/F Connector
(K)
PJ9999
RTC Battery I/F Connector
(L)
IS4004
SD Card I/F Connector
(M)
IC9
Clock Generator ICS950812
(N)
IC1500
I/O Controller Hub (ICH4-M)
(O) IC1508
YEBISU
3S
(P)
IC1510
PC Card Power Switch MIC2563A
(Q)
IC1511
SD Card Current-Limited Switch MAX1607ESA
(R) IC2000
EC/KBC
M306K9FCLRP
(S)
IC2018
RS-232 Transceiver MAX3243
(T)
IC2103
CD Play Controller OZ168
(U)
IC8972
Power Supply Controller (PSC)
(V)
DS1500
SD Card LED
(W)
DS2000
DC-IN LED (Green)
(X)
DS2001
DC-IN LED (Orange)
(Y)
DS2002
Power LED (Green)
(Z)
DS2003
Power LED (Orange)
