Appendices Apx.C Pin Assignments
C-28 Satellite Pro M10 Series Maintenance Manual (960-431)
VGA Board (FQDVG*)
C.30
PJ4205 LCD I/F Connector (40-pin)
Table C-30 LCD I/F connector pin assignments (40-pin)
Pin No. Signal name I/O Pin No. Signal name I/O
1 GND - 2 GND -
3 GND - 4 GND -
5 TXDT6-P3P O 6 GND -
7 TXDT6-P3N O 8 BRT2DA-S3P O
9 TXDT5-P3P O 10 PNL-P3V O
11 TXDT5-P3N O 12 PNL-P3V O
13 TXDT4-P3P O 14 BRT1-P5P O
15 TXDT4-P3N O 16 FL-P5V O
17 TXCK1-P3P O 18 FL-P5V O
19 TXCK1-P3N O 20 FL-P5V O
21 GND - 22 BRT0-P5P O
23 TXDT2-P3P O 24 GND -
25 TXDT2-P3N O 26 GND -
27 TXDT1-P3P O 28 GND -
29 TXDT1-P3N O 30 GND -
31 TXDT0-P3P O 32 GND -
33 TXDT0-P3N O 34 PNL2-P3P I
35 TXCK0-P3P O 36 PNL1-P3P I
37 TXCK0-P3N O 38 PNL0-P3P I
39 GND - 40 GND -
