Apx.C Pin Assignments Appendices
Satellite Pro M10 Series Maintenance Manual (960-431) C-23
C.18 PJ2040 USB Board (FQDUB*) I/F Connector (30-pin)
Table C-18 USB Board (FQDUB*) I/F connector pin assignments (30-pin)
Pin No. Signal name I/O Pin No Signal Name I/O
1 E5V O 2 E5V O
3 E5V O 4 E5V O
5 E5V O 6 E5V O
7 E5V O 8 E5V O
9 NC - 10 USBOC1-E3N I
11 USBON1-E5N O 12 GND -
13 USBOC0-E3N I 14 USBON0-E5N O
15 GND - 16 GND -
17 GND - 18 USBP3-S3P I/O
19 USBP3-S3N I/O 20 GND -
21 USBP2-S3P I/O 22 USBP2-S3N I/O
23 GND - 24 USBP1-S3P I/O
25 USBP1-S3N I/O 26 GND -
27 USBP0-S3P I/O 28 USBP0-S3N I/O
29 GND - 30 GND -
C.19 PJ4015 Video Out I/F Connector (2-pin)
Table C-19 Video out I/F connector pin assignments (2-pin)
Pin No. Signal name I/O Pin No. Signal name I/O
1 GND - 2 AV-PXP O
