Apx.C Pin Assignments
Appendices
Satellite Pro M10 Series Maintenance Manual (960-431)
C-15
C.11
PJ2003 Touch Pad I/F Connector (8-pin)
Table C-11 Touch Pad I/F connector pin assignments (8-pin)
Pin No.
Signal name
I/O
Pin No.
Signal name
I/O
1 P5V
O
2 IPDDAT-P5P
3 IPDCLK-P5P
4 GND
-
5 SP-GND
6 SPY-PXP
7 SPX-PXP
8 SP-P5V
C.12
PJ2007 Docking I/F Connector (242-pin)
Table C-12 Docking I/F connector pin assignments (242-pin) (1/4)
Pin No.
Signal name
I/O
Pin No.
Signal name
I/O
1 DCOUT
-
2 DCOUT
-
3 DOCDT1-S3N
I
4 P5V
-
5 MOUSCK-P5P I/O
6 EXKBCK-P5P
I/O
7 GND
-
8 PHYRST-E3N
O
9 DPCONF-S5P
I
10 GND
-
11 GND
-
12 DDCSCL-P5P
I/O
13 DRED-PXP
O
14 DGRN-PXP
O
15 DBLUE-PXP
I/O
16 OVSYNC-P3P
O
17 NC
-
18 NC
-
19 GND
-
20 NC
-
21 NC
-
22 NC
-
23 NC
-
24 NC
-
25 NC
-
26 NC
-
27 NC
-
28 GND
-
29 GND
-
30 NC
-
31 NC
-
32 NC
-
33 NC
-
34 NC
-
35 NC
-
36 NC
-
37 GND
-
38 NC
-
39 NC
-
40 NC
-
41 GND
-
42 NC
-
43 NC
-
44 NC
-
45 GND
-
46 NC
-
47 NC
-
48 NC
-
49 GND
-
50 NC
-
51 NC
-
52 NC
-
