4.11 Touch Pad 4 Replacement Procedures
Satellite Pro M10 Series Maintenance Manual (960-431) 4-43
2. Hold the palm rest with both hands and then slightly bend it to release two latches
securing each sides of the touch pad cover. Be careful not to bend the palm rest
excessively, or it will be broken.
3. Remove the touch pad cover and touch pad.
4. Disconnect the pad cable from the connector on the touch pad.
Palm rest
Touch pad cover and
Touch pad
Figure 4-28 Removing the touch pad
Installing the Touch Pad
To install the touch pad, follow the steps below and refer to Figures 4-27 and 4-28.
1. Connect the pad cable to the connector on the touch pad.
2. Assemble the touch pad cover and touch pad, and then seat them to secure them
with four latches.
3. Secure the touch pad with two M2.5 ×5 black flat-head screws and two M2.5×4
screws.
