Apx.C Pin Assignments
Appendices
Satellite Pro M10 Series Maintenance Manual (960-431)
C-31
Table C-31 System board (FQDSY*) I/F connector pin assignments (200-pin) (3/3)
Pin No.
Signal name
I/O
Pin No.
Signal name
I/O
137 NC
-
138 AV-PXP
O
139 NC
-
140 GND
-
141 CRTBLU-PXP
O
142 GND
-
143 CRTGRN-PXP
O
144 GND
-
145 CRTRED-PXP
O
146 GND
-
147 DBLUE-PXP
O
148 GND
-
149 DGRN-PXP
O
150 GND
-
151 DRED-PXP
O
152 GND
-
153 HSYNC-B3P
I/O
154 OVSYNC-B3P
I/O
155 GND
-
156 BRT0-P5P
I
157 BRT1-P5P
I
158 BRT2DA-S3P
I
159 1R5-P1V
I
160 1R5-P1V
I
161 1R5-P1V
I
162 1R5-P1V
I
163 NC
-
164 BVON-S5P
I
165 GND
-
166 BVON-S5N
I
167 2R5SNS-B2P
O
168 P5V
I
169 P5V
I
170 P5V
I
171 P5V
I
172 DDCSCL-P5P
I/O
173 DDCSDA-P5P
I/O
174 DPCONF-S5P
I
175 GND
-
176 GND
-
177 GND
-
178 GND
-
179 GND
-
180 PVON-S5P
I
181 15-EBV
I
182 NC
-
183 GND
-
184 GND
-
185 GND
-
186 NC
-
187 B3V
I
188 B3V
I
189 B3V
I
190 B3V
I
191 NC
-
192 GND
-
193 GND
-
194 GND
-
195 GND
-
196 NC
-
197 PVT-EFV
I
198 PVT-EFV
I
199 PVT-EFV
I
200 PVT-EFV
I
